Page 148 - 2021 Bunzl Buyers Guide Interactive Catalog

148
CLEANING/HYGIENE
1/2-inch rigid barb INCLUDED!
ITEM NO. 3047 0070 3047 0075 3047 00691 3095 0553 3013 10111 3013 00111
PRODUCT
EACH
M-70 Series Nozzles
Our premium heavy-duty industrial spray nozzle.
• Insulated replaceable rubber cover. • Variable spray pattern.
• Rated at 150 psi, +180 °F, flow rate: 7 gpm. • Field repairs are quick and easy. • Instant shut-off when trigger is released. • Weight: 2.9 pounds.
$206.95
206.95
206.95
2.95
23.45
28.85
M-70 Nozzle w/Black Cover
M-75 Nozzle w/White Cover
M-77 Nozzle w/Red Cover (not pictured) . . . . . . . . . . . . . .
Stainless Steel Hose Clamp . . . . . . . . . . . . . . . . . . . . . . . .
Opt . Brass Swivel Adapter 1/2" NPT x Female GHT . . . . . .
Opt . Stainless Steel Swivel Adapter 1/2" NPT x Female GHT . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . .
M-70 Series Replacement Parts
ITEM NO. 3047 0020 3047 1020 3047 0026 3047 0072 3047 4167 3047 4168 3047 4174 3047 4175 3047 0032 3047 4171 3047 01031 3047 2100 3047 4170
CD E F G H
PRODUCT
A . Replacement Black Cover
Replacement White Cover A
Replacement Red Cover
B. Replacement Body
C. Replacement Lever Arm
D. Replacement Stainless Steel Seat E. Replacement Lock Screw
F. Replacement Stem Guide
G. Replacement Body Sealing O-Ring H. Replacement Lever Arm Screw
I. Replacement Cartridge and Cage J. 1/2" Barrel Type Adapter
K. Replacement Lever Arm Bushing
B J
K
I
1/2-inch Female NPT Inlet.
Attach to standard garden hose with stainless steel hose clamp, sold separately.
 SEE PAGE 151 Item# 3095 0553
We recommend use with a
1/2 inch NPT
x female GHT, swivel adapter, sold separately.
Trigger lock with every adapter.
Vikan® Spray Gun
By applying a variable amount of tension on the rubber insulated trigger, the user can control the pressure of the water jet.
• Suitable for many cleaning applications including rinsing
off work surfaces and walls after chemical foaming.
• The water jet can also be adjusted using the screw at the end of gun.
• An arrow on the water gun indicates the spray direction of the water jet.
• 7-1/10 inches W x 5-7/10 inches L x 2-1/4 inches H.
• Maximum Temperature: 203 °F.
• Rubber on brass/stainless steel body.
ITEM NO. 5281 00331 5281 03591 5281 00321 H710 00871 5281 01451 5281 03381
COLOR
White Yellow Red Blue Green Black
EACH
$134.95
Swivel-Pro Hose Adapter
Increases nozzle control and flexibility, while
maximizing operator comfort and safety.
• Allows circular, horizontal and vertical movements of the nozzle without repositioning heavy hose.
• Minimizes stress on the wrist and forearm.
• Rubber coated boot for additional heat protection.
• For applications up to 50 psi and 200 °F.
Swivel-Pro adaptor allows for rotation and pivoting motion for ease of nozzle use.
NEED HOSE?
From General purpose to reinforced hot water hose — we've got the right hose for you!
ITEM NO. 3047 9012 3047 9013 3047 9014
F.O.B. FACTORY
PRODUCT EACH
1/2" . . . . . . . . . . . 5/8" . . . . . . . . . . . 3/4" . . . . . . . . . . .
 SEE PAGES 152-153 For Ordering Information
$193.95
193.95
193.95
BUNZL | KOCH Supplies
800-456-5624 | www.bunzlpd.com | FAX 800-329-5624 | kochsupplies@bunzlusa.com
PRICES ARE SUBJECT TO CHANGE • MINIMUMS MAY APPLY • VISIT OUR WEBSITE FOR CURRENT PRICING. HOT WATER NOZZLES
