Page 546 - 2021 Bunzl Buyers Guide Interactive Catalog

546
PLANT REMODELING
Flexible Airguard® Doors
Series 100 Doors
Models Numbers 100E and 100CE
• Meets USDA requirements.
• 45-ounce, heavy-duty, abrasion-resistant vinyl coated nylon.
• Large 30 x 14-inch vision panel made from shatterproof polycarbonate.
• Top mounted gravity actuated hinge provides completely automatic operation. Opens instantly upon contact and closes automatically by gravity.
• 48-inch heavy-duty, 1/8-inch thick Kydex® impact plates mounted front and back of each door.
• Available in green only.
UNIFLEX 240 PVC Door
Models Number 240PVC
• Constructed of two layers of 0.12-inch PVC heat welded together to a thickness of 0.24 inches and textured embossed finish.
• 15 x 14-inch clear vinyl window centered in each panel.
• Meets USDA requirements.
• Top mounted gravity actuated hinge provides completely automatic operation. Opens instantly upon contact, then closes automatically by gravity.
• Colors: navy, royal blue, chocolate brown, medium brown, forest green, red, metallic gray and black.
300 Belted Door
Models Number 300 Belted
• For heavy use forklift and/or freezer applications down to -30 °F.
• Wiper seals are provided at bottom and top.
• Balloon seals provided at jamb edge of each door.
• Window centered in each panel 15 inches x 14 inches.
• Constructed of two layers of abrasion-resistant, two-ply “belting” material bonded together.
• Top mounted gravity actuated hinge provides completely automatic operation. Opens instantly upon contact, then closes automatically by gravity.
• Available in green only.
973 Standard Forklift Doors
Models Number 973
• NOT for freezer applications.
• Constructed of 0.16-inch thick, PVC door body with a two-ply, vinyl coated nylon bracket pocket.
• Top mounted gravity actuated hinge provides completely automatic operation. Opens instantly upon contact, then closes automatically by gravity.
• Extra-large viewing area allows clear visibility and maximum safety.
• Balloon seals provided at jamb edge of each door, top and bottom wipers.
• Textured vinyl impact plates on both sides increases strength and durability of door.
• Colors: navy, royal blue, chocolate brown, medium brown, forest green, red, metallic gray and black.
F.O.B. FACTORY
Top Mounted Gravity Hinge – allows the door to open fully and close automatically. Optional
bracket arm adjustment feature compensates for jambs that are not plumb.
Vision Panel.
Model 100E (photo)
Model 100CE
Top Mounted Gravity Hinge – allows the door to open fully and close automatically. Optional
bracket arm adjustment feature compensates for jambs that are not plumb.
Top Mounted Gravity Hinge – allows the door to open fully and close automatically. Optional
bracket arm adjustment feature compensates for jambs that are not plumb.
Top Mounted Gravity Hinge – allows the door to open fully and close automatically. Optional
bracket arm adjustment feature compensates for jambs that are not plumb.
Vision Panel.
ORDER FLEXIBLE AIRGUARD® DOORS
Please have the following information available.
REMEMBER: Check your local building codes and/or with your local USDA inspector when buying products for your remodeling job.
Exact finished opening size (inches): Width __________ Height __________ Color: ____________________ Model:o100E o100CE o240 o300 o973 Traffic:oPeople oCarts oOther ____________________ Temperature: Inside __________ Outside __________
CALL 800-456-5624 FOR PRICING AND INFORMATION
BUNZL | KOCH Supplies 800-456-5624 | www.bunzlpd.com | FAX 800-329-5624 | kochsupplies@bunzlusa.com
PRICES ARE SUBJECT TO CHANGE • MINIMUMS MAY APPLY • VISIT OUR WEBSITE FOR CURRENT PRICING. FLEXIBLE DOORS
